Details

---

Special Features

• Stainless Steel Case Welded To Socket

• Dry or Liquid Filled Version

• Standard Followed :

• NSF/ANSI 61 Section 8-2016 NSF/ANSI 372-2016

• Helium Leak Tested

• Ready For Oxygen Use

• NSF Certificate for drinking water application

• IP:66

​

Specifications

• Ambient Temperature: -4°F(-20°C) to + 150°F(+65°C)

• Process Temperature: Max.392°F (200°C)

• Operating Pressure Range: 75% of Scale Value

• Over Pressure Limit: 125% of Max.Scale Value

• Case: AISI 304 SS Crimped Type

• Joints: Tig Argon Arc Welding

• Socket: AISI 304 SS

• Bourdon: AISI 316L SS

• Movement: Brass

• Dial: Aluminum

• Pointer: Fixed

• Window: PC lens

• Range: Vacuum to 10,000psi
