Details

---

Special Features

• CE Approved Transmitter

• Local Display With 4 To 20mA Output

• Stainless Steel Case & Measuring System

• Helium leak tested

• Standard Followed ASME –B.40.1 / EN837-1

• IP:54

​

Specifications

• Ambient Temperature: -4°F(-20°C) to + 150°F (+65°C)

• Process Temperature: Max.392°F (200°C)

• Operating Pressure Range: 75% of Scale Value

• Over Pressure Limit: 125% of Max.Scale Value

• Case: AISI 304 SS

• Joints: Tig Argon Arc Welding

• Socket: AISI 316L SS

• Bourdon: AISI 316L SS

• Dial:Aluminum

• Pointer: Mirco Zero Adjustable

• Window: Safety Glass

• Range: Vacuum to 7500psi

• Signal Output: 4-20mA DC(2-lime) 1-5V.DC(3-lime)

• Working Voltage: 24V.DC

• Element: Ceramic Sensor

• Junction Box: PVC
