Details

---

Special Features

• Phenolic Case With Solid Front Design

• Blow Out Back

• With Diaphragm Seal

• Standard Followed ASME –B.40.1

• Helium Leak Tested

• Built In Stabilizer Movement

• Ready For Oxygen Use

• Internal Vacuum /Over Pressure Stop

• IP:66

​

Specifications

• Ambient Temperature: -4°F(-20°C) to + 150°F(+65°C)

• Process Temperature: Max.392°F (200°C)

• Operating Pressure Range: 75% of Scale Value

• Over Pressure Limit: 150% of Max.Scale Value

• Case: Phenolic

• Joints: Tig Argon Arc Welding

• Socket: AISI 316L SS

• Diaphragm: AISI 316L SS

• Movement: AISI 304 SS

• Dial:Aluminum

• Pointer: Micro Zero Adjustable

• Window: Safety Glass

• Range: Vacuum to 6,000psi
