Details

---

Special Features

• All Welded Media Chamber

• Static Pressure Up To 600 psi

• Overload Safety Ensured by All Metal Construction

• Standard Followed ASME –B.40.1 / EN837-3

• IP:66

​

Specifications

• Ambient Temperature: -4°F (-20°C) to +150°F(+65°C)

• Process Temperature: Max.212°F (+100°C)

• Operating Pressure Range: 75% of Scale Value

• Over Pressure Limit: 125% of Max.Scale Value

• Case: AISI 304 SS

• Joints: Tig Argon Arc Welding

• Chamber: AISI 316 SS

• Diaphragm: AISI 316L SS

• Movement: AISI 304 SS

• Dial:Aluminum

• Pointer: Micro Zero Adjustable

• Window: Safety Glass

• Range: Vacuum to 15"WC-160psi
