Details

---

Special Features

• Wetted Parts AISI 316L Stainless Steel

• Dry or Liquid Version

• NACE MR 0175 Compliance

• Helium Leak Tested

• Internal Vacuum/ Over Pressure Stops

• IP:65

​

Specifications

• Ambient  Temperature :  -4 °F  (-20°C)  to  + 150°F (+65°C) Process  Temperature :  Max. 392°F  (200°C)

• Operating  Pressure  Range :  75%  of  Scale  Value

• Over  Pressure  Limit :  125%  of  Max. Scale  Value

• Case :  AISI  3 04  SS

• Joints :  Tig  Argon  Arc  Welding

• Socket :  AISI  316L  SS

• Bourdon:  AISI  316L  SS

• Movement :  AISI  304  SS

• Dial :Aluminum

• Pointer :  Fixed

• Contact: Silver-Nickel

• Window :  Safety  Glass

• Range :  Vacuum  to  10,000PSI
