Details

---

Special Features

• Die Cast Aluminum

• And Chrome body Part After 168 Hours Salt Bath Test

• The Final Coating Of Dark Gray Exterior

• Indicate Low Air Or Non-Corrosive gas

• Pressure-eighter Positive

• Negative(vacuum) Of Differential

• The Design Resists Shock

• Vibration and Over-pressures No Manometer Fluid To Evaporate

• Freeze Or Cause Toxic Or Leving Problems

​

Specifications

• Dimension: 4-3/4"dia.x2-3/16"Deep

• Weight: 1 1b.2oz.(510g)

• Fonished: Back Dark Gary Enamel

• Connection: 1/8"NPT(F) Hight And Low Pressure Taps Duplicated,One Pair Siad And One Pair Back

• Accuracy: +4% Of Full Scale,At 70°F(21.1°C)

• Pressure Rating: 15 psi(1.03bar)

• Ambient Temperature: 20-140°F(-7-60°C)

• Standard Gage Accessories:

• 1/8"NPT(M)Plugs For Duplicate Pressure Taps

• 1/8"NPT(M)Pipe Threat To Rubber Tubing Adapters And Three Flush Mounting Adapters With Screws
