Details

---

Specifications

• Accuracy: +3% Of The FSD (Ascending)

• Migration: Minor From High To Low Port

• Range: 0-0.25 to 0-10bar/psi or psi/kPa Dual Scale

• First Marking On The Scale: 15% Of The FSD

• Sensing Element: Magnetic Piston With Compression Spring

• Wetted Parts: SS316,SS 302 Compression Spring,Seals &       Ceramic Magnet

• Case Material & Dial Size:

• Stainless Steel (SS 304):2.5",3.5",4.0

• Engineering Polymer:2.5"

• Bayonet:4.0"

• Mounting: Direct,Front Flange,2"Pipe & Surface Mounting

• Maximum Working Pressure:100,250 & 400 bar

• Maximum Process Temperature: 0 to 80°C(32 to175°F)

• Enclosure: Engineering Polymer

• Seals: Buna-N & Viton

• Window: Float Glass(std.),Toughened Glass,Acrylic & Safety Glass

• Connection: 1/4"BSP(F) Std.Optional 1/4"NPT(F)

• Porting: In-Line

• Over Range Protection: Up To The Max.Working Pressure From High & Low Side

• Protection For Gauge & Switch: IP 65
