Details

---

Special Features

• Standard Followed ASME-B 40.1 / EN837-1

• Wetted Parts AISI 316L Stainless Steel

• Build in Stabilizer Movement

• Dry or Liquid Version

• NACE MR 0175 Compliance

• Helium Leak Tested

• External Zero Adjustable

• 40mmTemperature Compensated Blow Out Disc

• Internal Vacuum/ Over Pressure Stops

• High Range from 15,000 psi

• IP 66

​

Specifications

• Ambient Temperature:-4°F(-20°C) to +150°F (+65°C)

• Process Temperature:Max. 212°F (100°C)

• Operating Pressure Range:75% of Scale Value

• Over Pressure Limit:125% of Max.Scale Value

• Case:AISI 304 SS

• Joints:Tig Argon Arc Welding

• Socket:AISI 316L SS

• Bourdon:AISI 316L SS

• Movement:AISI 304 SS

• Dial:Aluminum

• Pointer:Micro Zero Adjustable

• Window:Safety Glass

• Range:15,000psi-60,000psi
