Details

---

Special Features

• Standard Followed ASME-B 40.1 / EN837-3

• Wetted Parts AISI 316L Stainless Steel

• Build in Stabilizer Movement

• Diaphragm Seal Integrally Built With Gauge

• Dry or Liquid Version

• NACE MR 0175 Compliance

• Helium Leak Tested

• Provides Best Hygiene Factor

• IP 65

​

Specifications

• Ambient Temperature: -4°F(-20°C) to + 150°F(+65°C)

• Process Temperature: Max.212°F (100°C)

• Operating Pressure Range: 75% of Scale Value

• Over Pressure Limit: 125% of Max.Scale Value

• Case: AISI 304 SS

• Joints: Tig Argon Arc Welding

• Socket: AISI 316L SS

• Bourdon: AISI 316L SS

• Movement: AISI 304 SS

• Diaphragm: AISI 316L SS

• Sanitary Seal: 1 1/2" in AISI 316 SS

• Dial: Aluminum

• Pointer: Fixed/Micro Zero Adjustable

• Window: Safety Glass

• Range: Vacuum to 600psi
