Details

---

Special Features

• Standard Followed ASME-B 40.1

• Phenolic Case With Solid Front Design Blow Out Back

• Wetted Parts AISI 316L Stainless Steel

• External Zero Adjustable

• Ready For Oxygen Service

• IP 65

​

Specifications

• Ambient Temperature: -4°F(-20°C) to+150°F (+65°C)

• Process Temperature: Max. 248°F (120°C)

• Operating Pressure Range: 75% of Scale Value

• Over Pressure Limit: 110% of Max. Scale Value

• Case: Phenolic

• Joints: Tig Argon Arc Welding

• Socket: AISI 316L SS

• Capsule: AISI 316L SS

• Movement: AISI 304 SS

• Dial: Aluminum

• Pointer: Fixed

• Window: Safety Glass

• Range: -250-0"wc to 0-250"wc
