Details

---

Special Features

• Stainless Steel Case Welded to socket
• Dry or liquid filled version (Standard follows ASME-B.40.1/EN837-1)
• Helium Leak Tested
• Built-in Stabilizer Movement
• Ready For Oxygen Use
• Internal Vacuum /Overpressure Stops
• IP 66

Specifications

• Ambient Temperature: -4°F (-20°C) to+150°F (+65°C)
• Process Temperature: Max. 392°F (200°C)
• Operating Pressure Range: 75% of scale value
• Over Pressure Limit: 125% of Max. scale Value
• Case & Bezel: SS304 Crimped
• Joints: TIG Argon Arc Welding
• Protection: IP 66
• Gasket: NBR
• Socket: AISI 316L
• Bourdon: AISI 316L
• Movement: AISI 304
• Dial: Aluminum
• Pointer: Fixed
• Window: PC Lens
• Gasket: NBR
• Ranges: Vacuum to 10,000psi
