Details

---

Special Features

• Economical Version
• General Purpose Applications
• Standard follows ASME-B.40.1/EN837-1

Specifications

• Ambient Temperature: -4°F (-20°C) to +150°F (+65°C)
• Process Temperature: Max. 250°F (120°C)
• Operating Pressure Range: 75% of scale value
• Over Pressure Limit: 120% of Max. scale value
• Case: ABS Plastic Case
• Joints: Alloy Brazing/Soldering
• Socket: Copper Alloy
• Bourdon: Copper Alloy
• Movement: Copper Alloy
• Dial: Aluminum
• Pointer: Fixed
• Window: Snap-in Plastic Lens
• Ranges: Vacuum to 1500 psi
