Details

---

Special Features

• Economical Version
• General Purpose Applications
• Standard follows ASME-B.40.1/EN837-1​

Specifications

• Ambient Temperature: -4°F (-20°C) to +150°F (+65°C)
• Process Temperature: Max. 250°F (120°C)
• Operating Pressure Range: 75% of scale value
• Overpressure Limit: 120% of Max. scale value
• Case: Steel, Powder Coated
• Joints: Alloy Brazing/Soldering
• Socket: Copper Alloy
• Bourdon: Copper Alloy
• Movement: Copper Alloy
• Dial: Aluminum
• Pointer: Fixed
• Window: Sheet Glass
• Ranges: Vacuum to 6000 psi
